All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.
Face Material:
Properties | Test Method | Result | ||
Grammage | ISO 536 | 80 g/m2 | ||
Caliper | ISO 534 | 86 microns |
Adhesive: AP903 A pure acrylic adhesive formulation
A pure acrylic adhesive offering good adhesion in wide temperature range, very good clarityfor wet and cold surfaces as for paper wine labels. Good adhesion and initial tack on apolar substrates (PE,PP)
Composition | Pure Acrylic |
Direct sunlight resistance | Good |
Cohesion | Low |
Application temperature ºC | -5ºC (minimum) |
Service temperature ºC | -40 +120 |
Tack FTM9 | 8 N/inch2 |
Ultimate adhesion FTM2 | 9 N/inch |
Laminate:
Laminate shelf life | 24 months stored at 20ºC/50% RH |
Typical laminate caliper | 164+/-6 ums (ASTM D374-88) |
Total weight | 167+/- 6 ( RIT.PP-032) |
WG White Glassine - 1 side siliconised supercalendered white glassine
Grammage | 65 gsm |
Caliper | 56 microns |
Transparency % | > 45% |
