Bauhaus Techplot - Dry Toner Unglued 80
Bauhaus Techplot - Dry Toner Unglued 80 is an uncoated woodfree bond paper perfect for architectural & engineering plan drawings. Compatible with Dry Toner and used with plan copiers.
Bauhaus Techplot - Dry Toner Unglued 80
Bauhaus Techplot - Dry Toner Unglued 80
Print Price
Material Description Price (exc. GST) Price (inc. GST) Qty Stock level
165361 Bauhaus Techplot 80g 594 x 150M x 76mm Unglued $60.13 / ROLL $66.14 / ROLL
? Order quantity has to be multiples of 2 SHEET
165367 Bauhaus Techplot 80g 841 x 150M x 76mm Unglued $88.40 / ROLL $97.24 / ROLL
? Order quantity has to be multiples of 2 SHEET
  • Perfect for architectural & engineering plan drawings
  • For use with plan copiers
  • Dry Toner systems
  • PEFC Certified
  • ISO 9001, ISO 14001, ISO 9706
  • NCOS (National Carbon Offset Standard)
​All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.​

Physical Properties


Unit

Typical Values

Method based on

Nominal Grammage


g/m²

80

AS 1301.405s

Grammage as made



80-83


Moisture
Thickness (bulking)


%
µm

4.5
104

AS 1301.157s
AS 1301.426s

Roughness (Bendtsen)

Porosity (Bendtsen)

TS
BS

Ml/min
ml/min
ml/min

120
140
1500

AS 1301.439s

AS 1301.440s

Cobb, 1 min (multi sheets)
Wax Pick

TS
TS, BS

g/m²
number

28
16

AS 1301.411s
Tappi 459

Visual Properties


Opacity
CIE Whiteness
Fluorescence (∆ Brightness)


TS
TS

%
D65/10°
%

92.0
160
25.0

AS 1301.454s
ISO 11475
AS 1301.462s

Colour L* (UV Exc)
Colour a* (UV Exc)
Colour b* (UV Exc)

TS
TS
TS

D65/10°
D65/10°
D65/10°

94.0
-0.4
-1.5

AS 1301.455s
AS 1301.455s
AS 1301.455s

Dirt Frequency

TS

Eba ppm

1.6

Tappi 563

MD = Machine Direction     CD = Cross Direction TS = Top Side BS = Bottom Side RC = Rapid Conditioned

The table above displays typical values. Test climate: RC @ 50%RH, 23°C.
