Ace Outdoor
Ace Outdoor is a 100% fibre based display board designed for short-term applications in outdoor or moisture sensitive environments.
Print Price
Material Description Price (exc. GST) Price (inc. GST) Qty Stock level
199200 Ace Outdoor 1220x2440 570g 0.9mm (BK) $18.40 / SHEET $20.24 / SHEET
? Order quantity has to be multiples of 10 SHEET
199686 Ace Outdoor 1220x2440 840g 1.25mm (BK) $26.93 / SHEET $29.62 / SHEET
? Order quantity has to be multiples of 10 SHEET
199204 Ace Outdoor 1220x2440 1000g 1.50mm (BK) $32.29 / SHEET $35.52 / SHEET
? Order quantity has to be multiples of 10 SHEET
199205 Ace Outdoor 1220x2440 1490g 2.20mm (BK) $48.17 / SHEET $52.99 / SHEET
? Order quantity has to be multiples of 10 SHEET
  • Recyclable & biodegradable
  • Sustainable and easy disposable alternative to PVC, polystyrene and polypropylene boards
  • Suitable for up to 12 weeks depending on environmental conditions
  • No plastic or PE coating
  • Recycled content in 1.25mm and above
  • FSC® certified (licensed code FSC® C010628)
  • Hanging signs
  • Header cards
  • Mounting board
  • Wet area signage
  • Bollards
  • Outdoor and Internal signage
  • Standees
  • POS display
  • Directional signage
  • Election signage
  • A Frames
  • Aisle Fins
PRINTING
• Offset printing (410gsm/520mic and 570gsm/900mic)
• Screen printing
• Large format digital printing

CONVERSION
• Embossing
• Foil and film lamination
• Varnishing
• Die cutting
• Creasing
• Perforating
• Cutting and scoring

All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.

SUBSTANCE
THICKNESS
BENDING RESISTANCE
L&W 15° mN
BENDING MOMENT
Taber 15° mNm
g/m2
mm
μm
pt
MD
CD
MD
CD
570¹
0.9
900¹
36
2475
1170
120
57
840
1.25
1250
49
2350²
1050²
*
*
1000
1.5
1500
59
*
*
*
*
¹suitable for direct food contact
²L&W 5° mN
*values cannot be measured


Tolerances / Testing Standards
Grammage (DIN ISO 536)±10%
Thickness (DIN ISO 534)±10%
Bending stiffness (ISO 5629)±20%
Printing Surface Properties
D65 Brightness TS (ISO 2470-2)80%
Surface smoothness (PPS) (ISO 8791-4)2.3μm

Outdoor Life

General life times refer to the durability of the unprinted face film when subject to vertical exposure in temperate, non‐extreme conditions. Actual performance life will depend on media and surface preparation and exposure conditions. For example the direction and angle of the sign; in areas of long, high temperature exposure; in areas of high pollution or high altitudes, outdoor performance will be decreased.

  • Suitable for UV curable inkjet printing and offset printing (in thinner gauges)

The material must be stored at a temperature of 22°C +/‐ 2°C and 50% +/‐ 5% of relative humidity. Do not expose to direct sunlight. The area must be dry and clean. Please keep the material in the original packaging when not used in order to protect it from dust and contaminations.
