- FSC® certified (licensed code FSC® C010628)
Recommended for high speeds labellings. Specially designed for product labels of high added value bottled in glass (wine, licquors, champagne, oil, water)
Cotone Bianco can be printed with a variety of processes from, Screen, foil, and offset-printing. Due to the high degree of porosity we recommend that a primer / varnish is used prior to applying high build screen embellishments.
All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.
Front Label
|
Reference |
COTONE EXTRA WHITE ULTRA WS |
|
General characteristics |
Natural 100% cotton paper with a high degree of whiteness, ULTRA WS and anti-fungus treatment. Due to the nature of the raw material used, there may be the small impurities and/or slight variations in tone and appearance which are normal in a natural product. |
|
Grammage (gr/m2) ISO 536 |
130 |
|
Thickness (µm) ISO 534 |
210 |
Adhesive
|
Reference |
SH-6020 PLUS |
|
General characteristics |
Permanent acrylic water based adhesive . Good adhesion to wet surfaces at low temperatures. Especially designed for glass containers, with excellent resistance to immersion in water/ ice. The research centre ISEGA has given the adhesive SH-6020 Plus approval according to the European requirements for indirect contact with foodstuffs and compliance with the rules of the Code of Federal Regulation s, FDA, 21 CFR Ch.l(April 1, 2013 edition) 175.105. According to the FDA regulations the adhesive must be separated from the foodstuffs by a functional barrier. |
|
Tack (N) glass FTM-9 |
>12 |
|
Cohesion (h) 1kg FTM-8 |
>2 |
|
Labelling temperature (0 C) |
>5°C |
|
Usage temperature (0 C) |
-10°C/+ ?S°C |
Support
|
Reference |
PET30 |
|
General characteristics |
Clear polyester film. |
|
Grammage (gr/m2) ISO 536 |
42 |
|
Thickness (µm) ISO 534 |
30 |
Note:
The ultra WS treatment of the face material avoids the creases formation and reduces the water absortion on the face surface. Due to the high stiffness of this product, it is not recommended for labelling small diameter curved surfaces (bottle neck labels,...). We recommend the reels to be wound with the face side out. The test of resistance to immersion in water-ice is carried out by sticking a blank(unprinted) label on a standard glass bottle. Five days after the label is stuck on, it is submerged in an ice bucket containing icy water for a minimum period of 4 hours and its resistance to immersion is checked.
Suitable for printing in Offset UV, Screen and hot foil
