Ace Kraft Screenboard
Ace Kraft is an uncoated display board with a natural, kraft surface on both sides that is ideally suited for large format digital printing.Premium, kraft twin sided rigid & dimensional stable display board. FSC Mix Certified.
- Natural kraft look & feel
- Clean pure centre
- Outstanding stay flat properties
- FSC® Certified (licensed code FSC® C010628)
- Fully Recyclable
- Biodegradable
- Hanging signage
- POS displays
- Aisle fins
- Header cards
- Category signage
- Promotional signage
- Shop window promotions
- Exhibition stands
- Mounting
All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.
SUBSTANCE | THICKNESS | BENDING RESISTANCE L&W 15° mN | BENDING MOMENT Taber 15° mNm | ||||
g/m2 | mm | μm | pt | MD | CD | MD | CD |
875 | 1.5 | 1500 | 59 | * | * | * | * |
1070 | 2 | 2000 | 79 | * | * | * | * |
1575 | 3 | 3000 | 118 | * | * | * | * |
*values cannot be measured |
Tolerances / Testing Standards Printing Surface Properties
Grammage (DIN ISO 536) ................................................. ±10% ISO Brightness .............................................
Thickness (DIN ISO 534) ................................................... ±10% CIE Whiteness D65/10° (ISO 11475) ............
Bending stiffness (ISO 5629) ............................................. ±20% Surface smoothness (Bendtsen) ..................1500 ml/min
Brightness C/2° (ISO 2470) ............................................... Gloss 75° (ISO 8254-1) ................................
Surface smoothness Bendtsen (ISO 8791-2) ...................
PRINTING
•Offset printing
• screen printing
• large format digital printing
CONVERSION
•embossing
• foil and film lamination
• varnishing
• die cutting
• creasing
• perforating
• cutting and scoring
