Ace High White Screenboard
A twin sided high white display board intended primarily for screen printing, the triple coated surface provides superior printing characteristics. Ace Hi White Screenboard also has outstanding bulk, thickness and stiffness.
- Coated both sides with bright, high white surface
- FSC® Certified (licensed code FSC® C010628)
- Super smooth surface
- Clean pure white centre
- High bulk & stiffness
- Ideally suited for hanging signage, POS displays, aisle fins, header cards, category signage, promotional signage, shop window promotions, exhibition stands & mounting
- Print Compatibility: Latex & UV Curable Inks.
- Hanging signage
- POS displays
- Aisle fins
- Header cards
- Category signage
- Promotional signage
- Shop window promotions
- Exhibition stands & mounting
All statements, technical information and recommendation are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed, and the following is made in lieu of all warranties of merchantability and fitness for the purpose: Sellers and manufacturer’s only obligation shall be to replace such quantity of the product proved to be defective. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.
SUBSTANCE | THICKNESS | BENDING RESISTANCE L&W 15° mN | BENDING MOMENT Taber 15° mNm | ||||
g/m2 | μm | pt | MD | CD | MD | CD | |
610 | 875 | 35 | 1595 | 795 | 77 | 38 | |
680 | 1000 | 39 | 2595 | 1310 | 125 | 63 | |
800 | 1250 | 49 | * | * | * | * | |
910 | 1500 | 59 | * | * | * | * | |
1170 | 2000 | 79 | * | * | * | * | |
1650 | 3000 | 118 | * | * | * | * | |
*values cannot be measured |
Tolerances / Testing Standards Printing Surface Properties
Grammage (DIN ISO 536) ................................................................. ±10% ISO Brightness 103
Thickness (DIN ISO 534) ................................................................... ±10% CIE Whiteness D65/10° (ISO 11475) 140
Bending stiffness (ISO 5629) ............................................................ -20% Surface smoothness (PPS) 2.5μm
Brightness C/2° (ISO 2470) ............................................................... Gloss 75° (ISO 8254-1) <27
Surface smoothness (ISO 8791-4) ....................................................
Grammage (DIN ISO 536) ................................................................. ±10% ISO Brightness 103
Thickness (DIN ISO 534) ................................................................... ±10% CIE Whiteness D65/10° (ISO 11475) 140
Bending stiffness (ISO 5629) ............................................................ -20% Surface smoothness (PPS) 2.5μm
Brightness C/2° (ISO 2470) ............................................................... Gloss 75° (ISO 8254-1) <27
Surface smoothness (ISO 8791-4) ....................................................
PRINTING
• Offset printing
• Screen printing
• Large format digital printing
For offset the recommended raster is max. 175 lpi.
CONVERSION
• Embossing
• Foil and film lamination
• Varnishing
• Die cutting
• Creasing
• Perforating
• Cutting and scoring
